J. A. ROBY | Model #CB3TOR

CUISINIÈRE 3.0 TOR

BMR Exclusive

Are you a fan of traditionnal cooking? Then the CUISINIÈRE TOR 3.0, exclusive to BMR, was made for you! In addition to offering two cooking spaces (oven and cooking surfaces) this appliance allows you to warm up your home, with recommended areas ranging from 1000 to 2500 sq ft. The CUISINIÈRE TOR 3.0 is equipped with a new heat transfer system to the 5 walls oven. The CUISINIÈRE TOR 3.0 respects the environment with emissions levels as low as 1.3 g/h and an efficiency of 78.6%.

Heats 1,000 - 2,500 ft²
Output 95,000 BTU
Burn time 5 - 8 hrs
Type of fuelWood
Recommended heating area1000 - 2500 pi²
Combustion length5 to 8 hours
Maximum output95 000 BTU
Firebox dimensionsWidth 18 ¼" / Height 10 ¾" / Depth 20"
Door opening dimensions15 ¾" x 10 ¼"
Maximum log length19"
Exteriors dimensionsWidth 51 ½" / Height 58 3/8" / Depth 28 5/8"
Type of chimney2100° F.
Exaust pipe diameter6"
Recommended chimney diameter6"
Minimum chimney height12'
Minimum clearances to combustiblesBack 16 3/8" / Side (Left) 12" / Side (Right) 7 ½" / Top 84" (measured from floor)
Weight610 lbs
Standard test - US emissionsUS EPA Method 28R
Standard test - Canada emissionsCSA B415.1-10
WarrantyLimited lifetime

MSRP : DETAILS IN STORE

Certifications

Share the product

Facebook
Email
J. A. ROBY INC.
490, rue de l'Argon
Québec, Qc Canada G2N 2C9
T. (418) 849-8095 | F. (418) 849-0077

FEATURES

  • Model with two cast iron doors
  • High efficiency CSA B415.1-10 certified appliance
  • EPA Exempt certified
  • Recommended heating area (sq.ft): 1000 – 2500
  • Color: Metallic black
  • Decorative chrome trim door (firebox side)
  • Handles, corners and chrome ornaments
  • Model: Freestanding
  • Convection and radiation heating system
  • Air-wash system on firebox system
  • Glass oven door
  • Cooking area 16″ X 47″
  • Food warmer
  • Thermometers on oven and food warmer
  • Low clearance to combustible material
  • Baffle: Fibre ceramic
  • Outdoor air intake
  • FIrebox lined with refractory bricks for better heat distribution
  • Stainless steel secondary air system improving gas combustin
  • Recomanded chimney: 6″
  • Low emissions 1.02 g/h
  • LHV 79,46 %
  • Log lenght 19″
  • Tested as per applicable standards by Intertek

Options

  • Decorative black top and mirror (TDDNM)
  • Decorative chrome top and mirror (TDDCM)
  • Outdoor air intake package kit (ECPAE)
  • Additional oven rack for cookstove (CUISINIEREGF)
  • Black enameled cast iron cooking plate, right (PLAQUECUID)
  • Black enameled cast iron cooking plate, left (PLAQUECUIG)
